D600 AE Diesel Pump
D600 AE Diesel Pump
A light weight portable diesel powered fire pump that combines the benefit of high pressure fire fighting performance with optimum water transfer properties.
Key Features
EASY TO USE CONTROL PANEL
Controls are easy to operate from one location and include Engine Electric Start, Engine Stop, Throttle Control, Battery Charge Indication, Oil Pressure Indication, Engine Hours Run Counter, Pump Pressure Gauge, Compound Gauge and LED Night Light.
SIMPLE AND RAPID PRIMING
Fast and effective priming is provided by the simple to operate stainless steel exhaust eject primer. The pump will prime 3 metres in 20 seconds and to a maximum of 6 metres.
HIGH PERFORMANCE DIESEL ENGINE
Kohler KD425, two cylinder diesel four stroke, Direct fuel injection, Forced air-cooled with fan flywheel, Full pressure lubrication through lobe pump, flyweight type governor to prevent over speeding. Engine displacement 851cc, Bore 85mm, Stroke 75mm, Max torque 42Nm @ 2200 rpm, 14kw (19 HP) @3600 rpm. Electric and Manual Rope Start.
CORROSION RESISTANT FRAME CONSTRUCTION WITH MULTI-DIRECTIONAL HANDLES
Exceptionally strong stainless steel frame with spring loaded handles to allow for multiple carrying positions. Stainless steel is used on all fabricated parts. Aluminium Alloy pump end. Fold down wheel set.
FEATURES AND SPECIFICATIONS
Marine Firefighting, Salvage Relief
Engine SPECIFICATIONS
Engine Series:
Kohler KD425
Description:
Twin air-cooled, overhead valve
Displacement:
851cc
Type:
4 cycle
Lubrication:
Full Pressure lubrication
Starting:
12 volt electric starter with Manual Recoil
Fuel Tank:
Integral 4 Litre – 1 hour run time
Battery:
Twin 12 volt VRLA
Maximum Power:
Maximum output 19HP @ 3600
Pump SPECIFICATIONS
Type of Pump Transfer:
Combination: Pressure/Volume
Intake:
4″ (100mm) BSRT or 3 1/2″ (75,,) Female BSP
Discharge:
Twin 64mm LG2 Globe Valves
Volute Body and Head:
Marine Grade Aluminium Alloy CC601 heat treated to T6 Hardness
Impeller:
Marine Grade Aluminium Alloy CC601 Fully Enclosed.
Wear Rings:
Long Wearing Acetyl, Economical to replace.
Shaft Seal:
Spring Loaded Mechanical
Priming:
Exhaust eject will prime 3 metres in 21 seconds and up to 6 metres
Frame Type:
Full Wrap Around Stainless Steel
Operating Controls
All the Operating Controls and Instrumentation are located in one area making it easy to read and operate:
FEATURES
- Engine ON/OFF/START switch
- Engine Hours Run Meter
- Throttle Control
- Choke Control
- Low Oil Pressure Warning Lamp
- Alternator Charge Warning Lamp
- Pump Pressure Gauge
- Pump Compound Gauge
- Fold Down Wheel Set
- LED Panel lighting
DIMENSIONS
